So start irw, point your remote and start pressing buttons. irw will output the commands received by the IR receiver that match your nf file.
#PC REMOTE RECEIVER SETUP INSTALL#
You may also need to install the gcc compiler. Installing the right version of the headers to match your kernel version is esssential. On my system this Ubuntu package was linux-kernel-headers-2.9.12-9-386 to match the version returned by the uname -a command. If you get an error message that the "kernel source is required", it actually means the kernel headers. You should change mceusb2 to mceusb if you are using the old version of the remote. configure -prefix=/usr -sysconfdir=/etc/conf.d -with-x -with-driver=mceusb2 If you get errors during the compile, try to change the. configure -prefix=/usr -sysconfdir=/etc/conf.d -with-x -with-driver=allĬp remotes/mceusb/ /etc/conf.d/nf If it complains about missing fedora source files use "yum install kernel-devel" and rerun. This will also create a /etc/nf file which should work. Note: If bash returns 'dialog not found' when running. If that still doesn't work, please report your issues to the lirc mailing list.
#PC REMOTE RECEIVER SETUP CODE#
If you have problems with the above install, or just want to run the latest and greatest lirc version, download the latest cvs lirc code using the following method. Users of the very latest linux kernels may find they have problems compiling or running code from the svn snapshot. Download and extract it either manually from the previous link or using the following code. As of writing, the latest snapshot available is lirc-0.8.7pre1. Generally the latest cvn snapshot from the official LIRC website should work fine. Use the default mceusb2 nf file and all of the remote's keys work without modifying the example mceusb2 nf file.
#PC REMOTE RECEIVER SETUP DRIVER#
This remote requires an updated lirc_mceusb2 driver (newer than current lirc-0.8.2 released: ) Download just the updated driver (version 1.30 of the file and newer has support) from LIRC CVS or follow the instructions below for a complete CVS checkout.
Before continuing, be sure your device is recognized by your USB host controller:Īnother newer remote (version 1069) now responds with the following when you type lsusb:īus 002 Device 002: ID 0609:0334 SMK Manufacturing, Inc. There is no kernel module specific for this device.
You will only need the USB 1.1 driver (OHCI or UHCI) and USB 2.0 (EHCI) is not required. The kernel module that lirc creates does not have 2.4 support.īe sure your kernel has support for USB. You must be using a 2.6 kernel for the newer remote. Only difference is the module name - it will be lirc_mceusb instead of lirc_mceusb2. I would think it's the same as the newer remote instructions below, but I can't verify. Note: The below assumes you are using LIRC, which is no longer required for basic setups not requiring LIRC's more complete feature set. You will probably have to add Keybindings in Myth for a few of your remote buttons.Depending on your distro, some re-mapping of remote button codes to keyboard scan codes may be required.Transmit (IR Blaster) support is unknown.There was a mod-mce project for early support, but modern kernels should support Version 1 & 2 USB receivers as HID devices out-of-the-box.IR Transmitter is supported with lirc_mod_mce > 0.1.3.Keyboard is supported as a USB HID device.They were merged into a single lirc_mceusb driver as of lirc-0.8.6, which as noted above, supports transmit and receive on all devices. Historically, there were separate 1st-gen and 2nd-gen drivers, lirc_mceusb and lirc_mceusb2.
#PC REMOTE RECEIVER SETUP FULL#
More recently (2.6.35 kernel and lirc-0.8.7) the module was known as just mceusb. These were later merged into a single lirc_mceusb driver. Note: Originally there were two modules lirc_mceusb and lir_mceusb2.
